Επισημάνσεις:
Αυτή η πλήρως ενθυλακωτική στεγανή στολή περιορισμένης διάρκειας ζωής τύπου 1A – ET έχει σχεδιαστεί για να προστατεύει τον ανταποκριτή έκτακτης ανάγκης από τοξικά ή διαβρωτικά αέρια, υγρά και στερεά χημικά.
Η στολή κατασκευάζεται από DuPont™ Tychem® TK, ένα πολύστρωτο, μη υφασμένο ύφασμα χημικού φραγμού υψηλής απόδοσης, το οποίο είναι επίσης ελαφρύ σε βάρος.
Χαρακτηριστικά προϊόντος:
- Σχεδιασμός ενθυλάκωσης για αυτοδύναμη αναπνευστική συσκευή (SCBA) που φοριέται μέσα στη στολή
- Στεγανό φερμουάρ από την πλευρά του κεφαλιού έως το κάτω μέρος του μηρού, που καλύπτεται από φερμουάρ με κούμπωμα με άγκιστρο και βρόχο.
- Προστασία έναντι υγρών και αέριων χημικών ουσιών (τύπου 1), μολυσματικών παραγόντων και παραγόντων χημικού πολέμου
- Δοκιμασμένη εσωτερική διαρροή σύμφωνα με το πρότυπο EN 1073-2:2002, κατηγορία 3 με ονομαστικό συντελεστή προστασίας (NPF) >9090
- Σύστημα στεγανής μανσέτας ασφάλισης για την αλλαγή γαντιών
- Διπλό σύστημα γαντιών που αποτελείται από ένα εσωτερικό γάντι Kemblok™ με χημικό φραγμό συνδεδεμένο με ένα εξωτερικό γάντι από νεοπρένιο για μηχανική προστασία.
- Δύο βαλβίδες εκπνοής διατηρούν μια άνετη πίεση εργασίας στο εσωτερικό της στολής
- Μεγάλο εύκαμπτο γείσο χημικής αντοχής για ευρύ οπτικό πεδίο
- Τα μανίκια με φτερά νυχτερίδας επιτρέπουν στον χρήστη να αφαιρεί το χέρι του από το γάντι για να ελέγχει τους μετρητές και άλλο εξοπλισμό στο εσωτερικό της στολής
- Ρυθμιζόμενη εσωτερική ζώνη στήριξης
- Επιλογή από σταθερές ή αποσπώμενες μπότες χημικής ασφάλειας ή πόδια με κάλτσες
- Δοκιμή εσωτερικής πίεσης σύμφωνα με το πρότυπο ISO 17491-1:2012 που διενεργείται πριν από την αποστολή για να επιβεβαιωθεί ότι η στολή είναι αεροστεγής
- Πενταετής διάρκεια ζωής χωρίς συντήρηση, με ετήσια δοκιμή από το έτος 5 έως τη μέγιστη διάρκεια ζωής των 10 ετών
Κατασκευαστής: Respirex
Μεγέθη
| Size | Στήθος (cm) | Ύψος (cm) |
| Small | 88-96 | 164-175 |
| Medium | 96-104 | 170-182 |
| Large | 104-112 | 176-188 |
| X-Large | 112-124 | 182-194 |
| XX-Large | 124-136 | 188-200 |
Instructions
ChemProtex
Instructions
Tychem
Δεδομένα Χημικής Διαπερατότητας
| Chemical | CAS Number | Tychem® TK | Chemprotex™ X |
|---|---|---|---|
| acetaldehyde | 75-07-0 | >480mins | >480mins |
| acetic acid, 30% | 64-19-7 | >480mins | |
| acetic acid, glacial | 64-19-7 | >480mins | >480mins |
| acetic anhydride | 108-24-7 | >480mins | >480mins |
| acetone | 67-64-1 | >480mins | >480mins |
| acetone cyanohydrin | 75-86-5 | >480mins | |
| acetonitrile | 75-05-8 | >480mins | >480mins |
| acetophenone | 98-86-2 | >480mins | |
| acrylamide 50% | 79-06-1 | >480mins | >480mins |
| acrylic acid | 79-10-7 | >480mins | >480mins |
| acrylonitrile | 107-13-1 | >480mins | >480mins |
| allyl alcohol | 107-18-6 | >480mins | >480mins |
| allyl chloride | 107-05-01 | >480mins | |
| ammonia gas | 7664-41-7 | >480mins | >480mins |
| ammonia solution, 35% | 1336-21-6 | >480mins | |
| ammonium hydroxide (35% NH3 in water) | 1336-21-6 | >480mins | |
| amyl acetate | 628-63-7 | >480mins | >480mins |
| aniline | 62-53-3 | >480mins | >480mins |
| aviation fuel | n/a | >480mins | |
| benzene | 71-43-2 | >480mins | >360mins |
| benzonitrile | 100-47-0 | >480mins | >480mins |
| benzoyl chloride | 98-88-4 | >480mins | >480mins |
| benzyl alcohol | 100-51-6 | >480mins | |
| benzyl chloride | 100-44-7 | >480mins | >480mins |
| bromine | 7726-95-6 | <10mins | |
| bromine liquid | 7726-95-6 | <10mins | |
| butadiene, 1,3- | 106-99-0 | >480mins | >480mins |
| butane | 106-97-8 | >480mins | |
| butanol n- | 71-36-3 | >480mins | >480mins |
| butyl acetate | 123-86-4 | >480mins | |
| butyl aldehyde | 123-72-8 | >480mins | >480mins |
| butyl ether n- | 142-96-1 | >480mins | >480mins |
| carbon disulphide | 75-15-0 | >480mins | >480mins |
| chlorine gas | 7782-50-5 | >480mins | >480mins |
| chloroacetic acid 85% | 79-11-8 | >480mins | |
| chlorobenzene | 108-90-7 | >480mins | >480mins |
| chloroethanol 2- | 107-07-3 | >480mins | >480mins |
| chloroform | 67-66-3 | >480mins | >60mins |
| chlorosulphonic acid | 7790-94-5 | >480mins | |
| cresol m- | 108-39-4 | >480mins | >480mins |
| cyclohexane | 110-82-7 | >480mins | >480mins |
| cyclohexanone | 108-94-1 | >480mins | |
| di(2-ethylhexyl)phthalate | 117-81-7 | >480mins | |
| dichlorodimethysilane | 75-78-5 | >480mins | |
| dichloromethane | 75-09-2 | >480mins | >480mins |
| diesel fuel | n/a | >480mins | >480mins |
| diethylamine | 109-89-7 | >480mins | >480mins |
| diethylsulphate | 64-67-5 | >480mins | |
| dimethyl sulphate | 77-78-1 | >480mins | |
| dimethyl sulphide | 75-18-3 | >60mins | |
| dimethylacetamide, N,N- | 127-19-5 | >480mins | >480mins |
| dioxane 1,4- | 123-91-1 | >480mins | >480mins |
| epichlorohydrin | 106-89-8 | >480mins | >480mins |
| ethanol | 64-17-5 | >480mins | |
| ethanolamine | 141-43-5 | >480mins | >480mins |
| ethyl acetate | 141-78-6 | >480mins | >480mins |
| ethyl benzene | 100-41-4 | >480mins | >480mins |
| ethyl cellosolve acetate | 111-15-9 | >480mins | >480mins |
| ethylene diamine | 107-15-3 | >480mins | |
| ethylene dibromide | 106-93-4 | >480mins | >480mins |
| ethylene dichloride | 107-06-2 | >480mins | |
| ethylene glycol | 107-21-1 | >480mins | |
| ethylene oxide | 75-21-8 | >480mins | >480mins |
| formaldehyde, 37% sol | 50-00-0 | >480mins | >480mins |
| formic acid 96% | 64-18-6 | >480mins | |
| furaldehyde 2- | 98-01-1 | >480mins | >480mins |
| glutaraldehyde 5% | 111-30-8 | >480mins | >480mins |
| heptane | 142-82-5 | >480mins | |
| hexamethylene diisocyanate | 822-06-0 | >480mins | |
| hexane | 110-54-3 | >480mins | >480mins |
| hydrazine | 302-01-2 | >480mins | |
| hydrazine monohydrate | 7803-57-8 | >480mins | |
| hydrochloric acid 37% | 7647-01-0 | >480mins | >480mins |
| hydrofluoric acid 48% | 7664-39-3 | >480mins | >480mins |
| hydrofluoric acid 73% | 7664-39-3 | >480mins | |
| hydrogen chloride gas | 7647-01-0 | >480mins | >480mins |
| hydrogen fluoride gas | 7664-39-3 | >480mins | >300mins |
| hydrogen fluoride liquid | 7664-39-3 | >480mins | >180mins |
| hydrogen peroxide 30% | 7722-84-1 | >480mins | >480mins |
| kerosene | 8008-20-8 | >480mins | |
| lactic acid | 50-21-5 | >480mins | |
| mercuric chloride (sat. solution) | 7487-94-7 | >480mins | >480mins |
| methacrylic acid | 79-41-4 | >480mins | >480mins |
| methanol | 67-56-1 | >480mins | >480mins |
| methyl acrylate | 96-33-3 | >480mins | >480mins |
| methyl chloride | 74-87-3 | >480mins | >480mins |
| methyl ethyl ketone (M.E.K) 2-butanone | 78-93-3 | >480mins | >480mins |
| methyl mercaptan | 74-93-1 | >480mins | >480mins |
| methyl methacrylate | 80-62-6 | >480mins | >480mins |
| methyl pyrolidone, n | 872-50-4 | >480mins | |
| methyl vinyl ketone | 78-94-4 | >480mins | |
| methyl-t-butyl-ether | 1634-04-4 | >480mins | >480mins |
| methylene bromide | 74-95-3 | >480mins | |
| nicotine | 54-11-5 | >480mins | >480mins |
| nitric acid (>90% fuming) | 7697-37-2 | >480mins | |
| nitric acid 70% conc | 7697-37-2 | >480mins | >480mins |
| nitrobenzene | 98-95-3 | >480mins | >480mins |
| nitromethane 96% | 75-52-5 | >480mins | |
| oleum (15% free SO3) | 8014-95-7 | >480mins | |
| oleum 40% SO3 | 8014-95-7 | >480mins | |
| oxalic acid saturated solution | 6153-56-6 | >480mins | |
| perchloric acid | 7601-90-3 | >480mins | |
| petrol – unleaded | 8006-61-9 | >480mins | >480mins |
| petrol, leaded | n/a | >480mins | >480mins |
| phenol 85% aqueous | 108-95-2 | >480mins | |
| phosgene | 75-44-5 | >480mins | |
| phosphoric acid 85% | 7664-38-2 | >480mins | >480mins |
| phosphorus oxytrichloride | 10025-87-3 | >420mins | |
| phosphorus trichloride | 7719-12-2 | >480mins | |
| potassium chromate (sat. solution) | 7789-00-6 | >480mins | >480mins |
| propan-2-ol | 67-63-0 | >480mins | |
| propylene oxide | 75-56-9 | >480mins | >480mins |
| pyridine | 110-86-1 | >480mins | >480mins |
| sodium cyanide 45% | 143-33-9 | >480mins | |
| sodium hydroxide 40% | 1310-73-2 | >480mins | |
| sodium hypochlorite (12% chlorine) | 7681-52-9 | >480mins | |
| styrene | 100-42-5 | >480mins | >480mins |
| sulphur dioxide | 7446-09-5 | >480mins | >480mins |
| sulphuric acid 50% | 7664-93-9 | >480mins | |
| sulphuric acid 95-98% | 7664-93-9 | >480mins | |
| sulphuric acid 99% | 7664-93-9 | >480mins | |
| tetrachloroethylene | 127-18-4 | >480mins | >480mins |
| tetraethyl lead (Octel Anti Knock) | 78-00-2 | >480mins | |
| tetrahydrofuran | 109-99-9 | >480mins | >480mins |
| toluene | 108-88-3 | >480mins | >480mins |
| toluene-2,4-diisocyanate | 584-84-9 | >480mins | >480mins |
| toluidine, o- | 95-53-4 | >480mins | >480mins |
| trichloroacetic acid 80% | 650-51-1 | >480mins | |
| trichlorobenzene, 1,2,4- | 120-82-1 | >480mins | >480mins |
| trichloroethane | 71-55-6 | >480mins | |
| trichloroethylene | 79-01-6 | >480mins | >30mins |
| triethylamine | 121-44-8 | >480mins | >480mins |
| trifluoroacetic acid | 76-05-1 | >480mins | |
| vinyl acetate | 108-05-4 | >480mins | >480mins |
| xylene | 1330-20-7 | >480mins | >480mins |
| ‘Roundup’ weedkiller | n/a | >480mins |
